Comparison Of Methanol Burner And Diesel Burner
Comparison Of Methanol Burner And Diesel Burner
First: Cost comparison
A ton of steam is calculated by a ton of steam boiler.
1. Diesel oil: the price is 9.0 yuan/kg, the calorific value is about 10200kcal / kg, the diesel oil consumption for producing 1 ton of steam is about 70kg, and the cost is 630 yuan/ton;
2. Methanol: the price is 3.5 yuan/kg, and the calorific value is about 5000 kcal/kg. About 140kg of methanol is required to produce 1 ton of steam, and the cost is 490 yuan per ton.
Through the comparison of the above examples, it can also produce 1 ton of steam, and the methanol boiler can save about 140 yuan in cost, and the cost-saving effect is very obvious.
Second: Use effect comparison
Methanol boilers do save money than diesel boilers. So, comparing the two oil-fired boilers, which one is better?
The advantages of the methanol boiler can be shown as follows:
1. Methanol is a new type of energy, which has no pollution to the environment and can be used in industrial parks and urban areas;
2. The working noise is low. The integrated fan relies on the burner and the servo motor operates automatically. The noise is less than 60 dB and will not cause noise pollution to the surrounding environment;
3. It has a wide range of energy sources. Methanol is a biofuel and has a wide range of sources. It is sold in major cities throughout the country, and the energy used is easy to obtain;
4. No opening fee is required. The opening of the natural gas pipeline requires a large amount of opening fee, which can be saved for the methanol boiler;
5. The fuel cost is low. Compared with natural gas and oil, the cost of methanol is low, which can effectively save operating costs.
The diesel engine has excellent performance, but it produces serious pollution during combustion. During the combustion of diesel engines, carbon dioxide, nitrogen oxide, etc. will be produced. The operation of the boiler will also produce the discharged sewage. The softened water regeneration agent will also produce wastewater, washing water, etc.
Third: Can methanol and diesel be used together?
The answer is No. Although methanol and ethanol belong to oil-fired boilers, the combustion modes of the two fuels are very different. Although methanol and diesel are both petroleum fuels, there are essential differences between them. Methanol is highly volatile and corrosive, and the atomization mechanism in the combustion process is different. Therefore, if the diesel boiler needs to use methanol, the original diesel burner and pipeline system should be replaced by the methanol burner and pipeline system.
